Automate fire sprinkler design from your floor plans.
Upload a DXF or DWG, and get a validated sprinkler layout, routing, hydraulic analysis, and review-ready deliverables — in minutes, not days.
Design Faster, Stay Compliant.
Skip the manual drafting. Upload your floor plan and get review-ready deliverables back before your coffee gets cold.
Minutes, Not Weeks
Full sprinkler layouts, routing, and hydraulic analysis delivered while you move on to the next job.
Everything Documented
Annotated CAD files, compliance reports, materials lists, and export-ready deliverables — nothing left to chase down.
Your Data, Your Control
Blueprints are encrypted, never shared, and only accessible to your team.
Grounded in Standards You Trust.
Every rule, check, and placement decision is grounded in NFPA® 13, 13R, 13D, and IBC standards. Nothing is guessed — every validation traces back to published fire protection codes.
NFPA® is a registered trademark of the National Fire Protection Association.
How It Works.
From floor plan to review-ready package in four steps.
Upload
Drop a DXF or DWG floor plan. The platform validates and normalizes your file on upload — unit resolution, layer classification, and multi-floor grouping happen automatically.
Analyze
Geometry is extracted, rooms are detected and classified, and doors, windows, and obstructions are identified — AI resolves ambiguous cases.
Design
Sprinkler heads are placed deterministically. Pipes are routed and sized. Hydraulic analysis runs. 27+ compliance checks validate everything with fail-closed defaults.
Review
Annotated CAD output, SVG preview, structured engineering reports, hydraulic analysis, and a materials list — ready to download and review.
Upload
Drop a DXF or DWG floor plan. The platform validates and normalizes your file on upload — unit resolution, layer classification, and multi-floor grouping happen automatically.
Analyze
Geometry is extracted, rooms are detected and classified, and doors, windows, and obstructions are identified — AI resolves ambiguous cases.
Design
Sprinkler heads are placed deterministically. Pipes are routed and sized. Hydraulic analysis runs. 27+ compliance checks validate everything with fail-closed defaults.
Review
Annotated CAD output, SVG preview, structured engineering reports, hydraulic analysis, and a materials list — ready to download and review.
Upload
Drop a DXF or DWG floor plan. The platform validates and normalizes your file on upload — unit resolution, layer classification, and multi-floor grouping happen automatically.
Analyze
Geometry is extracted, rooms are detected and classified, and doors, windows, and obstructions are identified — AI resolves ambiguous cases.
Design
Sprinkler heads are placed deterministically. Pipes are routed and sized. Hydraulic analysis runs. 27+ compliance checks validate everything with fail-closed defaults.
Review
Annotated CAD output, SVG preview, structured engineering reports, hydraulic analysis, and a materials list — ready to download and review.
From Floor Plan to Submittal.
Every step from DWG to deliverables, automated and traceable.
Built for Your Team.
FireDesign.ai gives your engineers and designers leverage — not a replacement. Stay in control, review and override anything, and approve deliverables on your terms.
Live Progress
Real-time job updates with stage-by-stage status so your team always knows where a design stands.
Workspaces
Personal and organization workspaces with tenant-scoped access control and signed download URLs.
Project Tracking
Job history, reconfigure-and-retry, and per-project artifact management across your team.
Frequently Asked Questions.
No. FireDesign.ai generates design proposals and review-ready deliverables, but licensed engineer review is still required for certification, site-specific supply decisions, and AHJ approval.
DXF and DWG floor plans. The platform validates and normalizes files on upload, handling unit resolution, layer classification, and multi-floor grouping automatically.
NFPA® 13, 13R, and 13D rules are encoded. Current implementation strength is residential design, with configurable standard, occupancy hazard, and head model selection.
The platform defaults to fail-closed behavior. Rule errors stop the design rather than passing silently, and auto-fix runs with bounded iterations and cycle detection. Items the software cannot safely certify are flagged for manual review.
Annotated DXF (and DWG when conversion succeeds), SVG preview, a structured engineering report with confidence scoring, compliance results, hydraulic analysis, materials list, and an engineer review checklist. Every stage produces inspectable intermediate artifacts for full traceability.
Yes. The platform supports personal and organization workspaces with tenant-scoped access, live job progress tracking, project-level artifact management, and signed download URLs.
Outputs are compatible with industry-standard tools like HydroCAD and AutoSPRINK. You can export validated layouts and hydraulic data directly into your existing workflow.
